VL80 RGB Torch

Technical Specifications

• Model: AMH VL80
• Type: Pocket RGB LED light
• Dimensions: 145 × 80 × 12 mm
• Weight: 240 g
• Materials: Aluminum alloy + PC
• Power switch: Toggle switch
• Power port: USB Type-C

Power & Battery

• Total power: White 10 W / Warm 10 W / Neutral 10 W / RGB 6 W
• Power supply: Built-in battery
• Input voltage: 4 V
• Input current: 2 A
• Output voltage / current: 3 V / 3.5 A
• Output power: 10 W
• Charging input: 5 V / 2 A
• Charging output: 4.2 V / 2.3 A
• Battery capacity: 4,000 mAh
• Charging time: approx. 140 minutes
• Battery life: up to 1.5 hours at full power

Lighting Performance

• CRI: ≥ 95 Ra
• Color temperature: 2700 K – 7500 K
• Luminous flux: 650 lm (White) / 580 lm (Warm) / 600 lm (Neutral)
• Dimming range: 1% – 100%
• Adjustment: Control knob

Lighting Modes

• CCT: White / Warm / Neutral
• HSL: Full color control from 0–360°
• FX: 13 built-in lighting effects

Light Source

• Light source: SMD LED
• LED count: RGB 48 pcs / White 45 pcs / Warm 45 pcs
• Substrate: Fiberglass board
• Power per LED: 0.5 W

Mounting & Control

• Mounting: Copper threaded mount (tripod / camera mount compatible)
• Control: Manual adjustment directly on the body

Box Contents

• 1 × AMH VL80 RGB LED Light
• 1 × USB-C charging cable
• 1 × Dual hot shoe mount
• 1 × User manual
